Wheel Factory hand built wheels
Spank Wing 22 rims are disc specific, tubeless ready, clincher rim, optimized for mixed on/off road use
Moderate 22mm inner width, provides exceptional versatility in tire pairing, from wide road slicks to gravel knobbies
Deep well 24.5mm profile height, enhances aero properties, as well as stiffness and torsional rigidity
Bead Nip tubeless bead seats provide reliable tubeless performance even at low pressures
Dynamal alloy is shot peen finish, heightening durability and fatigue life
Bitex BX106 Hubs offer premium performance and finish at an attainable price point
Black and Oil-Slick ( inch-OS inch part numbers) hub options available.
44 POE 6 pawl driver mechanism
XDR (BI4503) and Campy 11sp (BI4513) FHB available
Q/R axles and adapters available (BI4711-BI4713)
Black double butted spokes and brass nipples
Built with DT Swiss Competition double butted spokes (2.0/1.8/2.0) and brass DT Swiss Squorx nipples
Hand laced and trued in the USA
| size |
700c |
| front/rear |
rear (XDR) |
| rim |
Spank Wing 22 |
| hub |
Bitex BX106R CL |
| axle/spacing (mm) |
12x142 TA |
| hole |
32h |
| spoke |
DB |
| nipple |
brass |
| color |
black |
| weight |
930g |
