MTB XC25

Contact us for availability and Special Orders!

The ultra-light XC25 is a narrow rim that is looking for a challenge, both in competitive races and on your favourite trails. You can turn up the intensity on all kinds of terrain, from asphalt to field trails, forest trails, gravel and even scree slopes.

Handmade in Germany.

Technical Details

• Material Carbon
• Range of Use XC

RIM DETAILS

• Size 27.5″ | 29″
• Height 25 mm
• External Width 30.4 mm
• Internal Width 25 mm
• Rim Flange Width 2.7 mm
• Hole Count 28 | 32
• ERD 550 mm | 587 mm
• Asymmetrical Offset 2 mm
• Weight 350 g | 380 g
• Weight Tolerance 5 %
• Weight Limit none
• Colors UD-Finish: black


WHEELSET DETAIL

• Front wheel 15 x 110 mm Boost
• Rear wheel 12 x 148 mm Boost
• Hub DT Swiss 240 oder 350
• Freewheel SRAM XD | Shimano HG | Microspline
• Spokes Sapim CX-Ray | black
• Nipple Sapim | Aluminium | black | internal
• Rim Tape including
• Weight 1.410 g | 1.490 g (DT Swiss 240)
• 1.490 g | 1.560 g (DT Swiss 350)
• Weight Tolerance 5 %
• Weight Limit none

With the special layup architecture in the rim flange, it is the most robust rim in its weight class. Due to its low weight and correspondingly low moment of inertia, it provides unparalleled acceleration. You’ll definitely feel the edge you have over your competitors when you hit the mountains.

We meticulously spoke our wheels by hand.
