MTB TR30

Contact us for availability and Special Orders!

The TR30 closes the gap between the XC30 and the ED30. This rim offers a stronger layup than the XC30 but it's still slightly lighter than the ED30. It's the right choice for passionate amateurs or professional cyclists.

Handmade in Germany.

Technical Details

• Material Carbon
• Range of Use Trail | All Mountain

RIM DETAILS

• Size 27,5″ | 29″
• Height 25 mm
• External Width 36 mm
• Internal Width 30 mm
• Rim Flange Width 3 mm
• Hole Count 28 | 32
• ERD 550 mm | 587 mm
• Asymmetrical Offset 2 mm
• Weight 455 g | 485 g
• Weight Tolerance 5 %
• Weight Limit none
• Colors UD-Finish: black


WHEELSET DETAILS

• Front wheel 15 x 110 mm Boost
• Rear wheel 12 x 148 mm Boost
• Hub DT Swiss 240 or 350
• Freewheel SRAM XD | Shimano HG | Microspline
• Spokes Sapim D-Light | black
• Nipple Sapim | Aluminium | black | external
• Rim Tabe including
• Weight 1650 g | 1710 g (DT Swiss 240)
• 1710 g | 1780 g (DT Swiss 350)
• Weight Tolerance 5 %
• Weight Limit none

We meticulously spoke our wheels by hand.
