Road RX40
Installation Available
Smiles For Free
Contact us for availability and Special Orders!
Super-light and super-stiff for crazy acceleration. You’ll love every turn of your pedals. The new geometry with modern inner width is optimized for 25mm wide tires and the laminate is designed for maximum stiffness. This has made the rim the embodiment of pure speed on the road.
Handmade in Germany.
Len Imes, an expert in computational fluid dynamics (CFD) from iXent in Munich and former professor at Stevens Institute of Technology, has subjected our RX40 rim profile to aerodynamic analysis and optimized it using CFD for minimum air resistance in various riding scenarios.
We meticulously spoke our wheels by hand.
Tubeless Ready | Hooked Design | Disc Only | Aerodynamically Optimized
DESIGN & INNOVATION AWARD 2021 – WINNER
“The rims of the Beast RX40 wheelset are handcrafted in Dresden and paired to DT Swiss 240s Disc Center Lock hubs with 24 Sapim CX-Ray spokes – handcrafted meets proven quality. A concept with which Beast is able to produce a stiff, high end wheelset that is also quite light at 1329 g, despite the relatively high number of spokes. For aerodynamic reasons, the nipples are concealed inside the hookless carbon rim, which is fashionably wide with an inner rim width of 20 mm. Quick in acceleration, unaffected crosswinds and an absolute eye-catcher at the ice cream parlor! The RX40 wheelset doesn’t have a weight limit and is a premium upgrade for your bike, both technically and optically.”
| Material | Carbon |
| Range of Use | Road |
| RIM DETAILS | |
| Size | 700C |
| Height | 40 mm |
| External Width | 27 mm |
| Internal Width | 21 mm |
| Rim Flange Width | 2 mm / 3,1 mm |
| Hole Count | 24 |
| ERD | 557 mm |
| Offset | – |
| Weight | UD- and SQ-Finish: 400 g +25 g with color |
| Weight Tolerance | 5 % |
| Weight Limit | none |
| Colors | black | red | blue |
| WHEELRIM DETAILS | |
| Front wheel | 12 x 100 mm |
| Rear wheel | 12 x 142 mm |
| Hub | DT Swiss 180 and 240 |
| Freewheel | SRAM XDR | Shimano HG |
| Spokes | Sapim CX-Ray and Sprint | black |
| Nipple | Sapim | Aluminium | black | internal |
| Weight | UD- and SQ-Finish: 1.360 g (DT Swiss 180) UD- and SQ-Finish: 1.410 g (DT Swiss 240) +40 g with color |
| Weight Tolerance | 5 % |
| Weight Limit | none |
